Warranty: 3years

Place of Origin: Guangdong, China

Brand Name: Go-Gold

Model Number: KG-2450DC36

Usage: Electric Window Electric Curtain

Type: Gear Motor

Torque: 90 mN.m

Commutation: DC

Protect Feature: Totally Enclosed

Speed(RPM): 6000-10000RPM

Continuous Current(A): 1.5A

Efficiency: 80%

Product Name: Electric Curtains Motor DC Motor

Motor type: DC Motor

Certification: CCC Ce RoHS

Rated Voltage: 6-36V/custom Made

Keywords: Blind Motor

Noise: Low

Material: Cooper Wire

Sample

Application

What is a DC motor?

A DC motor is an electric motor that converts DC electrical energy into mechanical energy. Due to its excellent speed regulation performance, it has been widely used in electric drive. DC motors are divided into three types based on excitation methods: permanent magnet, separate excitation, and self excitation. Self excitation is further divided into three types: parallel excitation, series excitation, and compound excitation.

What is the composition structure of a DC motor?

1. The stator of a DC motor consists of components such as the frame, main magnetic pole, reversing magnetic pole, front and rear end caps, and brush holder. The main magnetic pole is the main component that generates the air gap magnetic field of the DC motor, and is composed of permanent magnets or laminated iron cores with DC excitation windings.

2. The rotor of a DC motor is composed of components such as an armature, a commutator (also known as a commutator), and a shaft. The armature is composed of two parts: an armature iron core and an armature winding. The armature iron core is made of silicon steel sheets stacked together, with teeth evenly distributed at its outer circle, and the armature winding is embedded in these grooves.

Advantages of DC motors

1. Best starting and speed regulation performance, wide and smooth speed regulation range, strong overload capacity, and less affected by electromagnetic interference.

2. DC motors have good starting and speed regulation characteristics.

3. The torque of DC motors is relatively high, and maintenance is relatively cheap.

4. DC motors are more energy-efficient and environmentally friendly compared to AC motors. DC motors have good speed regulation performance, relatively inexpensive maintenance, strong overload capacity, and are less affected by electromagnetic interference.
