Warranty: 1-3 Years

Place of Origin: Guangdong, China

Brand Name: Go-Gold

Model Number: KG-6095M23

Usage: Home Appliance, Grill Oven

Type: AC Shade Pole Motor

Commutation: AC

Protect Feature: Drip-proof

Feature: High Efficiency

Product Name: Grill Ovens Motor AC Motor

Motor type: AC Motor

Certification: CCC Ce RoHS

Rated Voltage: 208-230 / 240V / Custom Made

Keywords: Ovens Motor

Noise: Low

Material: Cooper Wire

Drawings

Sample

Application

Working Principle

Electromagnetic induction and magnetic field interaction

The working principle of shaded pole motors is mainly based on electromagnetic induction and magnetic field interaction. 12. This type of motor is a single-phase AC motor characterized by the fact that the magnetic poles of the stator (i.e. the outside of the motor) are partially surrounded by one or more short-circuit rings (also called "shield rings" or "shadow rings") shield. When the stator winding is connected to a single-phase AC power supply, alternating magnetic flux is generated in the stator core. These flux lines pass through the short-circuit ring, creating an induced current in the short-circuit ring. Due to the presence of the short circuit loop, the magnetic flux is different from that of the unshielded part and also lags behind the unshielded part in phase. This difference results in the formation of a pulsating, approximately rotating magnetic field in the motor air gap.

This rotating magnetic field cuts through the rotor (i.e. the rotating part inside the motor) and creates an induced current in the rotor windings. The interaction between the current-carrying rotor windings and the rotating magnetic field of the stator creates a starting torque, causing the rotor to start rotating. The direction of rotation of the rotor is usually from the unshielded part to the shielded part.

Feature

1. The structure design is reasonable, the lead-out direction is flexible, and the cathode motor junction box itself can be rotated and installed.

2. Superior shielded pole motor, low noise, low vibration, high performance protection level.

3. Multiple options to meet various user needs and install thermistors.

4. Adopt optimized design, high efficiency and significant energy saving effect.

5. Install various requirements, such as dust seals, heating bands, oil seals, oil filling, special shaft extensions, special flanges, etc.

Structure

The cathode motor is mainly composed of rotor parts, stator parts, wire package parts, bracket parts and connecting fasteners. The rotor component is mainly composed of a cast aluminum rotor, a shaft, a thrust washer to prevent the rotor from moving forward and backward, and a washer to adjust the displacement; the stator component is mainly composed of a short-circuit ring and the main stator core; the wire package component is mainly composed of coils, frames, wires or thermal Composed of sensitive resistors. It consists of a protector and related insulating packaging materials; according to the different installation positions of the axial extension end and the non-axial extension end, the bracket assembly is divided into a front bracket assembly and a rear bracket assembly.

• What is the function of shaded pole motor?

A shaded pole motor is an AC motor that is mainly used to drive an oven fan. Through the operation of the fan, the air inside the oven is circulated and the heat is evenly distributed on the surface of the food, thereby ensuring that the baked food has a beautiful color, fragrance and fresh taste.

• Why do ovens need shaded pole motors?

1. Improve oven efficiency

The temperature inside the oven usually has a certain degree of temperature difference. If a fan is not used for circulation, the higher temperature areas will generate higher heat on the food, which can easily lead to uneven baking. After using a shaded pole motor, the operation of the fan can evenly distribute the temperature and improve the thermal efficiency of the oven.

2. Reduce oven power consumption

Using a shaded pole motor for air circulation can quickly and evenly distribute the temperature on the food surface, thereby shortening the baking time and reducing the power consumption of the oven. This is not only good for the environment, but also saves people’s electricity costs.

3. Easy to clean and maintain

Since the shaded pole motor is installed inside the oven, it is also easier to clean and maintain. By removing the housing of the shaded pole motor, you can easily clean the debris and dust inside and keep the oven hygienic.
